Delo Syn - ATF XV

prices available on login

Delo Syn ATF XV is a high performance synthetic automatic transmission fluid designed for applications requiring a Volvo 97342 transmission fluid. Delo Syn ATF XV and is also suitable for use in a number of transmissions used by Japanese and Korean passenger car manufacturers.

High performance synthetic automatic transmission fluid (Supersedes Ursa Syn-ATF XV)

Delo Syn ATF XV is formulated with synthetic base fluids in combination with an optimised additive system.

Benefits

  • Synthetic base oil and oxidation inhibitor combination offers long fluid service life and resistance to sludge, lacquer and deposits
  • Robust shear stability promotes consistent viscosity retention throughout fluid service lifetime
  • Advanced formula helps protect against gear, bearing and clutch wear, increasing uptime
  • Optimised viscosity formulation promotes improved vehicle fuel economy
  • Friction modifier technology formulated to provide durable smooth shifting, efficient power transfer, and anti-shudder protection

Applications

  • Delo Syn ATF XV is designed to meet the Volvo 97342 specification, which is specified for the “HT” series of automatic countershaft transmissions used in Volvo wheel loaders and motor graders, and in the fully automatic PowerTronic (“PT”) planetary transmissions used in Volvo articulated haulers and some Volvo truck models
  • The oxidation stability of the synthetic base oils in the formulation means that compared to conventional fluids, Delo Syn ATF XV can offer significantly longer service intervals; and its temperature resistance means that it may be used in more arduous operating conditions
  • Delo Syn ATF XV has a lower kinematic viscosity than is typical for fluids used in this type of application - it has been optimised to improve machine efficiency while still providing protection for the machine components
  • The high Viscosity Index means that the fluid has a wide operating temperature window. This is achieved by formulating the product with synthetic base oils with a naturally high VI, plus a highly shear stable viscosity index (VI) improver. This combination helps maintain the viscosity and VI at a consistent level throughout the fluid’s service lifetime
  • The frictional properties of Delo Syn ATF XV make it suitable for use in a number of transmissions used by Japanese and Korean passenger car constructors. Delo Syn ATF XV may also be used in power assisted steering systems that permit the use of automatic transmission fluids

Specifications

  • Aisin Warner
  • Allison
  • Bosch
  • Honda
  • Hyundai/Kia/Mitsubishi
  • JASO
  • Mazda
  • Nissan
  • Subaru
  • Toyota
  • Voith
  • Volvo

Approvals

  • 97342 (AT 102) [1]
  • Volvo
  • Allison TES-389
  • Voith H55.6335.xx Recommendations
  • Aisin Warner JWS 3309
  • Aisin Warner JWS 3324
  • Bosch TE-ML 09
  • Honda ATF-Z1
  • Hyundai/Kia/Mitsubishi Diamond SP-III
  • JASO M315 Тype 1-A
  • Mazda ATF M5
  • Nissan MATIC-J
  • Subaru ATF-HP
  • Toyota Type T-IV
  • Toyota WS

Typical test data

Test Test Methods Results
Shelf Life: 60 months from date of filling indicated on the product label
Viscosity, Kinematic, 100°C, mm²/s ASTM D445 6.4
Viscosity, Kinematic, 40°C, mm²/s ASTM D445 32.0
Viscosity, Brookfield, -40°C, mPa.s ASTM D2983 12,000
Viscosity Index ASTM D2270 158
Density, 15°C, kg/l ASTM D1298 0.846
Flash Point COC, ºC ASTM D92 228
Pour Point, ºC ASTM D5950 -53

Source: PDS 20 December 2017 · Product Data Sheet
