Delo Syn - TDL SAE 75W-90

Premium performance fully synthetic Total Driveline Lubricant

Delo ® Syn-TDL SAE 75W-90 is a premium performance fully synthetic Total Driveline Lubricant offering extended drain capability, designed for API GL-4 and API GL-5 applications, and offers good thermal stability in higher temperature operations.

Delo Syn-TDL SAE 75W-90 is formulated with fully synthetic base oils in combination with an advanced high performance additive system.

Benefits

• Specially tuned friction characteristics make the product suitable for use in many synchronised manual transmissions and final drives, allowing inventory rationalisation
• Offers significantly longer service than conventional mineral gear oils in many applications - up to twice as long in transmissions and three times as long in drive axles
• Long-drain capability helps reduce overhaul and maintenance downtime
• High performance advanced additive system provides reliable extreme pressure protection and wear resistance
• Low-temperature fluidity offers component protection by allowing rapid oil circulation during cold weather start-up
• High Viscosity Index and good shear stability help provide viscosity and film thickness sufficient for effective high temperature lubrication throughout fluid service life

Applications

• Delo Syn-TDL SAE 75W-90 is designed for use in automotive manual transmissions and hypoid drive axles which require a fluid with API GL-4, GL-5 or MT-1 performance. It is approved against standard SAE J2360 (former MIL-PRF-2105E)
• The thermal stability makes Delo Syn-TDL SAE 75W-90 suitable for use in applications with higher operating temperatures than is possible when using mineral gear oils. The special characteristics of the synthetic base oils lead to a reduction in the operating temperature, further extending the service capability in arduous operating conditions, or improving fuel economy in normal service conditions. It is capable of significantly longer service intervals than conventional mineral gear oils in many applications: up to twice as long in transmissions and more than three times as long in drive axles. (The precise service interval varies according to application and service severity – refer to the manufacturers’ literature for further details)
• Delo Syn-TDL SAE 75W-90 is not recommended for use in ZF transmissions fitted with intarders (this includes some models from constructors such as DAF and MAN). For these exceptions, use an approved fluid such as Delo Syn-MTF XZ 75W-80

Approvals

• Daimler Truck DTFR 12B140 (Previously MB 235.8)
• Detroit Diesel DFS Axle Gear Oil Specification 93K219.01 341 Type Z2 [15]
• MAN 342 Type S1 [15]
• MAN
• SAE J2360
• Scania STO 1:1G
• Scania STO 2:0 A FS 97312 [13]
• Volvo TE-ML 02B [4]
• ZF TE-ML 05A [4]
• ZF TE-ML 12L [4]
• ZF TE-ML 12N [4]
• ZF TE-ML 16F [4]
• ZF TE-ML 17B [4]
• ZF TE-ML 19C [4]
• ZF TE-ML 21A [4]
• API GL-4
• API GL-5
• API MT-1 TE-ML 08 [12]
• Bosch Gearbox oil for Eaton gearboxes [5]
• DAF Gearbox oil for ZF gearboxes [1]
• DAF Rear axle without hub reduction [6]
• DAF Rear axle with hub reduction [7]
• DAF 3343 Type S [8]
• MAN
• NATO 0-226 STO 1:0 [3]
• Scania TE-ML 07A [9]
• ZF TE-ML 12B [10]
• ZF Suitable for use 341 Type E3 [14]
• MAN TE-ML 05B [11]
• ZF TE-ML 21B [11]

Typical test data

Source: PDS 28 November 2025 · Product Data Sheet

Opgelet: voor de meest recente PDS-informatie, ga naar https://cglapps.chevron.com/sdspds/HomePage.aspx?tab=pds
