Textran V 32

prices available on login

Textran V 32 is a high performance transmission/hydraulic fluid developed for use in heavily loaded torque converters and turbo transmissions.

High performance transmission/hydraulic fluid

Textran V 32 is formulated with premium Group II base oils in combination with selected high performance additives.

Benefits

  • High performance anti-foam and air release contributes smooth, reliable operation
  • Oxidation resistance aids protection against in-service oil thickening and harmful sludge formation
  • EP performance helps prevent critical wear and scoring in bearings and other vulnerable components
  • Low temperature fluidity promotes reliable performance and wear protection during cold starts
  • Comprehensive rust and corrosion protection

Applications

  • Textran V 32 is designed for use in the following applications:
  • Voith turbo couplings in industrial, marine and railway equipment
  • Voith torque converter transmissions in shunting locomotives and heavy duty construction equipment
  • Voith hydrodynamic brakes in railway and heavy duty automotive equipment It may also be used in moderately loaded gearboxes and hydraulic systems. Note that Textran V 32 is not designed to provide rapid water separation, so should not be used in applications where this performance is required

Approvals

  • Voith Turbo 120.00059010, Index 2 Turbo transmissions (former 3.285-149)
  • Voith Turbo 3625-006058 Geared variable speed couplings type R…B with bevel gears of sizes 1 to 4
  • Voith Turbo 3625-006072 Variable speed turbo couplings type S, Torque converters type E
  • Voith Turbo 3625-008426 Geared variable speed couplings type R, Torque converters with gear stage(s) types EA and EH

Typical test data

Test Test methods Results
Shelf Life: 60 months from date of filling indicated on the product label.
Appearance Visual Pale yellow
Density, 15°C, kg/l ASTM D4053 0.859
Pour Point, °C ASTM D97 -43
Flash Point COC, °C ASTM D92 216
Viscosity, Kinematic, 100°C, mm 2 /s ASTM D445 5.7
Viscosity, Kinematic, 40°C, mm 2 /s ASTM D445 33
Viscosity, Kinematic, 20°C, mm 2 /s ASTM D445 87
Viscosity Index ASTM D2270 114
Air Release, min DIN 51381 1.3
FZG Gear Wear Test A/8.3/90, CEC L7A95 >12
Failure load stage

Source: PDS 05 March 2015 · Product Data Sheet
